DIAMOND UPDATE 2.46.0.0

Diamond update 2.46.0.0 : extended support and new ECU solutions!

Marelli 11GF control units , allowing programming of FCA mild hybrid engine ECUs . It is now possible to perform tuning to improve performance and simplify recovery and cloning operations, transferring the complete backup from a damaged unit to a working one without having to have both vehicles in the shop.

In addition, there is an exclusive for VAG 3.0L TDI engines: unlocking and OBD programming of Bosch MD1CS014 ECUs with the latest anti-tuning protections. It is no longer necessary to remove the ECU from VAG vehicles produced since July 2020: just download the virtual reading from the database and unlock the control unit.

Some of the supported vehicles

  • Fiat Panda Mild Hybrid 1.0L FireFly 70PS – 2020
  • Fiat 500 Mild Hybrid 1.0L FireFly 70PS – 2020
  • Lancia Ypsilon Mild Hybrid 1.0L FireFly 70PS – 2020
  • Audi A6 3.0L 45TDI V6 250PS
  • Audi A8 3.0L 50TDI V6 290PS
  • Audi Q7 3.0L 50TDI V6 290PS
  • Audi SQ5 3.0L 50TDI V6 345PS
  • Volkswagen Touareg 3.0L 50TDI V6 290PS

Added protocols (OBD)

AG Bosch MD1CS014 TC299TP Virtual Read/Write/ Checksum Calculation

Writing time: ~ 2 minutes

Added Protocols (BOOT)

FCA Marelli 11GF TC277 Read / Write / Checksum Internal Flash;
Read /Write Internal EEPROM;
                                            Full Backup / Clone

Reading time: ~ 50 seconds minutes
Writing time: ~ 40 seconds
Tempo di scrittura: ~ 40 secondi
